Applications

Ceramic Slurry Pump (Exported to Manono) ● Model: TZJK-18MN-95TD (450mm diameter) ● Flow rate: 2600 m³/h ● Head: 42m

● Feed Pump for Cyclone ● Concentration: 45%, Flow rate: 1800 m³/h, Head: 48m, Particle size: 15-20mm ● Model: TZJK-300-1000TD ● Original metal pump: 50-60 days ● Ceramic pump: 9 months (s...

● Copper Scavenging Foam Pump ● Replaced an imported brand ● Zhanggu Ceramic Foam Pump has achieved 7 times the service life and is still in operation.

Primary Cyclone Feed Pump ● Model: TZJK-YN15-56TD ● Slurry Concentration: 55-60% ● Maximum Particle Size: 15-20 mm ● Original Metal Pump Lifespan: Less than 2 months ● Zhanggu Ceramic Pump Lif...

Primary Cyclone Feed Pump ● Model: TZJK-DP-566T ● Slurry Concentration: 55-60% ● Maximum Particle Size: 20 mm ● Original Rubber Pump Lifespan: Approximately 15 days ● Zhanggu Ceramic Pump Life...

Tower Mill Discharge Pump ● Model: TZJK-DT-656T ● Slurry Concentration: 35-45% ● Operation Start Date: December 19, 2019 ● Original Metal Slurry Pump Lifespan: 25-28 days ● Lifespan: Continuou...

Tailings feed Pump ● Model: TZJK-XSH-858T ● Flow Rate: 700 m³/h ● Head: 120 m ● Concentration: 35% ● Maximum Particle Size: 3-25 mm ● Lifespan of Flow Components: Over 6 months

Titanium Concentrate Transfer Pump (Flotation) ● Model: TZJK-BC-502T ● Flow rate: 90 m³/h ● Head: 100m ● Slurry concentration: 35-45% ● pH: <3 ● Original metal pump: 15-20 days ● Cer...

Iron Concentrate Transfer Pump ● Model: TZJK-AB-523T ● Flow rate: 140 m³/h ● Head: 115m ● Speed: 1600 r/min ● Original service life: Around 30 days ● Current service life: Over 5 months

Middlings Pump ● Model: TZJK-HX-C450TD ● Slurry concentration: 55% ● -200 mesh content: 50% ● Original metal pump: 15 days ● Ceramic slurry pump: Over 5 months

Primary Cyclone Feed Pump (with 25-30mm steel balls) ● Ceramic pump model: TZJK-350-1100TD, Flow rate: 2400 m³/h, Concentration: 60% ● Original metal wear parts: 28 days ● Current ceramic w...

Ansteel GuanbaoshanPrimary Grinding Cyclone Feed Pump● Model: 350mm diameter ceramic pump● Motor: 6-560 KW● Original metal wear parts: 50-60 days● Ceramic pump: Over 250 days
